Case IH Extended Deep-Dish Pressure Doors

Shop by Image

Download

Cotton pickers are necessary machinery for cotton farmers to make the harvesting process more manageable. Cotton farmers should stay on high alert on new agriculture technology, which helps maintain productivity. At Certi-Pik, USA, we endeavor to provide the highest quality cotton picker parts in the market. If you’re looking for parts for the Extended Deep Dish Doors on your Case IH Cotton Picker, we are your trusted sourcing partner.

Learn More

Tips for Buying Miscellaneous Components for Your Case IH Cotton Harvester

Your cotton picker components may fail due to wear and tear, possibly the result of poor maintenance, or poor quality. If your Case IH cotton harvester needs components replacement, use the following tips to buy them:

Consider the Quality

We always tell farmers they should use high-quality parts that will not fail during the crucial harvesting period. Purchasing our aftermarket high-quality Case IH miscellaneous parts for your Module Express™ cotton picker ensures a speedy harvest and long-lasting product, saving you money that you would have spent otherwise if you purchased OEM or other source components.

What You Need to Know
About your Extended Deep Dish Doors

The function of the extended deep-dish door is to allow for more efficient cotton collection, due to a deeper, longer, and more rigid picking zone minimizing door warpage from plant pressure, thus pulling more cotton into the baskets during regular operation. In addition to increasing efficiency, the extended deep-dish doors shorten the overall time spent in the cotton field. The CTX extended deep-dish doors are equipped with an improved design in the scrapping plates on the front doors which use all the barbs on the spindle, unlike the regular OEM scrapping plates which might only use 3 barbs, this in turn can help increase the amount of cotton processed in your cotton picker by 14 to 30 percent. The rear CTX Case IH doors use the OEM style scrapping plate number 669576R2 as the front door takes care of the majority of the picking.

In addition to the scrapping plates, which come with attaching hardware, the above improvements of the Case IH CTX style doors provide you with a one-piece design which will eliminate the costly problems and downtime that results from the rear extension falling off after the pivoting hinge has worn through. Optionally, a removable extension is available for the front door if you want to more easily swing open the door to check the condition of your picking unit. With the new design of the door, plugging problems have been virtually eliminated and the removable extension is rarely used. You will be pleased to know that Case IH adapted our design to be used on their Module Express machines, so if you ever question our product, know that the OEM manufacturers considered ours a worthy upgrade to their machinery. For a smoother harvest, cotton farmers should regularly inspect their machinery for potential failures. Failures due to loose, missing, or worn-out parts can completely halt the harvesting process, which is unsuitable for your business. Farmers should replace worn-out parts from reputable companies licensed to sell products like Certi-Pik USA in order to receive high-quality, aftermarket parts for your Case IH cotton picker.

Parts For Your Case-IH Extended Deep Dish Doors

Whether you run our CTX doors, or the OEM style doors, which require more maintenance, inspection, repair, replacement, and maintenance of the cotton picker doors helps owners stay on top of minor issues resolved to avoid significant problems in the future.

Some of the components to consider when purchasing the extended deep-dish doors include:

  • Pressure Plates / Doors: These should be inspected often by operations personnel as they will experience regular wear and tear from use, requiring replacement.
  • Rods Hinges and Springs: These parts used with the optional removable extension on the front doors can easily experience damage over continued use.
  • Scrapping Plates: These parts tend to become worn down over time decreasing picking efficiency.
  • Extensions, Clamps, and Bushings: These may wear, and break after several harvests.

You need to get your cotton pickers running properly prior to the harvesting season to avoid any possibilities of delaying the harvest process. You can even pre-purchase the parts that require frequent replacement to have them at your disposal during harvest. This way, if there is a breakdown, the pieces are immediately accessible. Extended deep-dish doors and their components are available at Certi-Pik USA, ranging from doors to bushings, extensions, extension clamps, scrapping plates, and springs.

READ MORE

Contact Certi-Pik, USA Today

Certi-Pik USA has genuine extended deep-dish door components, and we can have the parts shipped to you as efficiently as possible. Our products come with a 90-day warranty in case the product sent to you is faulty, and the replacement is shipped to you for free. Certi-Pik USA has easy ordering, fast shipment and offers multiple ways to pay for the parts whether by Visa, money orders, cash on delivery, MasterCard, or Discover. Contact us today at (712) 752-8460 or fill out our online contact form.

Certi-Pik, USA Single Pik – Extended Deep-Dish Pressure Doors

Picking Unit Cabinet

1.1 – #CTX46337

Description: Single Pik – CTX ExtenDoor – CASE/IH- R.H. FRONT GUIDE (SOLD WITH: CTX20CL, CTX20FE & HARDWARE: 5x 01540P & 5x 10213P) REP. ALL 2000 SER. THRU 635 M.E. OEM GUIDES (USES 3x #669970 S.P.) (ILLUSTRATED)
OEM Part: 87669791
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

1.2 – #CTX46336L

Description: Single Pik – CTX ExtenDoor – CASE/IH – L.H. UNITS – 2022, 2044, 2555 (SOLD WITH: CTX20CL, CTX20FE, & HARDWARE: 5x 01540P & 5x 10213P) REPLACES OEM GUIDE #1546336C2 AND EXT. #1982710C2
OEM Part: CTX46336L
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

2 – #CTX20CL

Description: CASE/IH 2000 SERIES – ANGLE, EXTENSION CLAMP
OEM Part: 87689115
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

3 – #CTX20FE

Description: CASE/IH 2000 SERIES – EXTENSION, PLASTIC, FRONT
OEM Part: 87689109
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

4 – #CTX20PL

Description: CASE/IH 2000 SERIES – REMOVABLE EXTENSION, FRONT DOOR, STRONGLY RECOMMENDED – (ATTACHES WITH OEM SPRING ROD #’S 673851R3, 10322R, & 1982712C1)
OEM Part: 87689108
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

5 – #CTX20TB

Description: CASE/IH – BUSHING – REAR DOOR – OPTIONAL – (REPLACES: OEM 1x 86982778-SPACER & 2x 216544C1-BUSHING)
OEM Part: CTX20TB
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

6.1 – #CTX46345

Description: Single Pik – CTX ExtenDoor – CASE/IH – R.H. REAR GUIDE (SOLD WITH: CTX20CL, CTX20RE & HARDWARE: 5x 01540P & 5x 10213P) REP. ALL 2000 SER. THRU 635 M.E. OEM GUIDES (USES 3x #69576R2 S.P.) (ILLUSTRATED)
OEM Part: 87669794
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

6.2 – #CTX46344L

Description: Single Pik – CTX ExtenDoor – CASE/IH – L.H. UNITS – 2022, 2044, 2555 (SOLD WITH: CTX20CL, CTX20RE, & HARDWARE: 5x 01540P & 5x 10213P) REPLACES OEM GUIDE #1546344C2 AND EXT. #1982711C2
OEM Part: CTX46344L
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

7 – #CTX20RE

Description: CASE/IH 2000 SERIES – EXTENSION, PLASTIC, REAR
OEM Part: 87689114
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Ctx93029

8 – #CTX93029

Description: Single Pik – CTX ExtenDoor – JD – PRESSURE PLATE – FRONT & REAR – (9960-9965 IN-LINE) REPLACES OEM# AN193029 – ( THIS DOOR USES 3x #669970 SCRAPPING PLATES)
OEM Part: CTX93029
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

9 – #93844

Description: EXTENSION – FRONT (9935,9960-9965)
OEM Part: AN193844
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

10 – #98851

Description: ANGLE – EXTENSION CLAMP, FRONT & REAR (9935,9960-9965)
OEM Part: N198851
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

11 – #96126

Description: EXTENSION – PLASTIC, FRONT & REAR, (9935,9960-9965)
OEM Part: N196126
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

12 – #34274K

Description: PIN KIT – INCLUDES: 1x #34274-PIN, 1x #19488P-SPRING, 1x #33504P-SNAP RING
OEM Part: 34274K
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

13 – #98712

Description: REINFORCEMENT – PRESSURE PLATE (9935-CP770 – IN-LINE & PRO) 2x / 18S PLATE, 3x / 20S PLATE
OEM Part: N198712
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Ctx74593f

14.1 – #CTX74593F

Description: Single Pik – CTX ExtenDoor – JD – PRESSURE PLATE – PRO 16 20S : FRONT (9976-CP770) & REAR (7760&CP770) – REPLACES OEM #AN274593 & AN279558 – ( THIS DOOR USES 3x #669970 & 1x #669971 SCRAPPING PLATES)
OEM Part: CTX74593F
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Ctx74593r

14.2 – #CTX74593R

Description: Single Pik – CTX ExtenDoor – JD – PRESSURE PLATE – PRO 16 20S : REAR (9976-9996) REPLACES OEM #AN274593 – (THIS DOOR USES 3x #669970 & 1x #669971 SCRAPPING PLATES)
OEM Part: CTX74593R
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

15 – #72944

Description: EXT. – FRONT PRESSURE PLATE, PRO-16 20S (9976-CP770)
OEM Part: AN272944
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

16 – #74102

Description: ANGLE – EXTENSION CLAMP, PRESSURE PLATE, PRO-16 20S (9976-CP770) (AR: 6x 01519-1″-BOLT & 6x 10215P-NUT)
OEM Part: N274102
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

17 – #10467

Description:

EXTENSION – PLASTIC, PRESSURE PLATE, PRO-16 20S, FRONT & REAR – REPLACES #N274104 : (7760-CP770)

OEM Part: KK10467
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

18 – #75113K

Description: PIN KIT – INCLUDES: 1x #75113-PIN, 1x #19488P-SPRING, 1x #33504P-SNAP RING
OEM Part: 75113K
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Ctx74587f

19.1 – #CTX74587F

Description: Single Pik – CTX ExtenDoor – JD – PRESSURE PLATE – PRO 12 18S : FRONT (9970-CP770) REPLACES OEM #AN274587 & AN279557 – (THIS DOOR USES 3x #669970 SCRAPPING PLATES)
OEM Part: CTX74587F
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Ctx74587r

19.2 – #CTX74587R

Description: Single Pik – CTX ExtenDoor – JD – PRESSURE PLATE – PRO 12 18S : REAR (9970-CP770) REPLACES OEM #AN274587 – (THIS DOOR USES 3x #669970 SCRAPPING PLATES)
OEM Part: CTX74587R
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

20 – #74542

Description: EXTENSION – FRONT PRESSURE PLATE, PRO-12 18S (9970-CP770)
OEM Part: AN274542
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

21 – #78107

Description: ANGLE – EXTENSION CLAMP, PRESSURE PLATE, PRO-12 18S, (AR: 5x 01519-1″-BOLT & 5x 10215P-NUT) (9970-CP770)
OEM Part: N278107
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

22 – #78108

Description: EXTENSION – PLASTIC, PRESSURE PLATE, PRO-12 (9935-9996)- 18S (FRONT & REAR)- SUBS TO #KK10468: (7760-CP770)
OEM Part: N278108
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

23 – #669970

Description: CTX (5-SPINDLE) SCRAPPING PLATE – SOLD WITH ATTACHING HARDWARE- 2 BOLTS, & NUTS, NOT USED W/ REAR CASE
OEM Part: 669970
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

24 – #669971

Description: TOP (2-SPINDLE) CTX SCRAPPING PLATE – SOLD WITH ATTACHING HARDWARE – 2 BOLTS, & NUTS, (1 ON TOP OF 20 SPIN. DOOR)
OEM Part: 669971
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

25 – #69576R2

Description: SCRAPPING PLATE- LARGE CASE/IH OEM STYLE – SOLD WITH ATTACHING HARDWARE- 2 BOLTS, & NUTS (FITS REAR CASE CTX DOORS, AND FRONT & REAR OEM DOOR EXTENSIONS)
OEM Part: 669576R2
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Ctx79558fin

26.1 – #CTX79558FIN

Description: Single Pik – CTX ExtenDoor – JD – PRESSURE PLATE – WELDED STEEL SCRAPPING FINS – PRO 16 20S : FRONT (9976-CP770) & REAR (7760&CP770) – REPLACES OEM #AN274593 & AN279558
OEM Part: CTX79558FIN
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Ctx79558finr

26.2 – #CTX79558FINR

Description: Single Pik – CTX ExtenDoor – JD – PRESSURE PLATE – WELDED STEEL SCRAPPING FINS – PRO 16 20S : REAR (9976-9996) REPLACES OEM #AN274593
OEM Part: CTX79558FINR
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

27 – #07192P

Description: BOLT – M10 X 30 ROUND HEAD – SQR NECK
OEM Part: 03M7192
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

28 – #01730P

Description: WASHER – .410 X 1.5 X .120″
OEM Part: 24H1730
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

29 – #63526P

Description: NUT – M10 – SERR HEX FLANGE
OEM Part: E63526
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

30 – #01709P

Description: BOLT – 5/16 X 1″ CARRIAGE
OEM Part: 03H1709
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
Picking Unit Cabinet

31 – #10213P

Description: NUT – 5/16 – SERR HEX FLANGE
OEM Part: 10213P
Section: Picking Unit Cabinet
Certi-Pik, Usa Single Pik- Extended Deep-Dish Pressure Doors
