If you are looking to replace components of the air system of your John Deere cotton picker, the quality and delivery guarantee of the parts is vital. At Certi-Pik USA, we offer unmatched quality pieces that have a 90-day warranty. This assures you in terms of quality for all your purchases. Besides, we have been serving our customers with nothing but the best replacement pieces since 1988. Our skilled and well-trained team of professionals is also a phone call away to accord you all the assistance you need. Being a member of the Federation of Independent Business and accredited by the Better Business Bureau, quality is guaranteed. Having said that, let’s look at what we have available for you when it comes to John Deere cotton picker air systems.

Learn More

John Deere Air System

The air system in your John Deere cotton picker is a crucial component and a determinant of the productivity of your harvester. For this reason, only invest in the best quality to avoid frequent equipment failure during harvesting. Here is how the air system works to enable your harvester to remain productive. First, it’s the air system that keeps cotton moving freely during harvesting by preventing blockages. Blockages are prone to happen when the cotton you are harvesting is damp or the duct work is worn thin: creating snags or low air pressure.

The air system relays action throughout the parts of the machine, beginning with the discharge compartment, which serves the doffers and picker drums. It also discharges air through the discharge opening in the jet post, thus diminishing the accumulation of dust and debris on the bottom of the cabinet that may lead to clumping and clogging. The airflow through the system is predictable, hence moving cotton in large volumes to the suction duct and the basket opening. Failure of any air system components will halt the harvesting process, which directly impacts its productivity. Therefore, ensure you outsource the best air systems from Certi-Pik USA to prevent any inconveniences and conduct regular maintenance and cleaning.

Ordering Process of Air System Parts

We primarily stock the rear and front suction doors of your standard John Deere air system. This includes in-line, pro versions of the doors, as well as the specialty skip row configurations. In addition, you will find limited supplies of the older versions of the right and left suction doors in our catalog. You will also find other accessories like nuts, pins, bolts, and latches, among others.

During your process of ordering any part of the cotton picker air system, the part number, OEM part number, and description are the most important. This helps our team identify the parts you need correctly and avoid mistakes that may inconvenience both of us for shipping the wrong item. After you select the right part, your shipping and delivery method is not only reliable but quick. For this reason, we have established a good reputation with our customers as the reliable, quick, and quality supplier of the best cotton picker air system parts worldwide.

Why Buy from Certi-Pik, USA?

Besides prioritizing the convenience of our esteemed customers, below are other reasons why you should purchase your cotton picker air system from us.

  • The process of ordering is straightforward through email, fax, or call our sales department team. We are available at any time during regular business hours to answer all your questions and help you in ordering the parts you need.
  • Our shipment process (UPS or freight) is fast, with orders placed before afternoon shipped the same day, and those ordered in the afternoon shipped the next business day.
  • Quality of our products is guaranteed with a 90-day warranty for any defects on materials or manufacturing.
  • We offer our customers various payment options like MasterCard, wire transfer, Visa, American Express, Discover, Money orders, and cash on delivery.

READ MORE

Contact Certi-Pik, USA Today!

Our skilled team is available to answer any questions and address concerns with your cotton picker air systems. You can talk to one of us at (712) 752-8460. Besides, you can also fill our online contact form, and our team will be glad to be of service.

John Deere Front & Rear Suction Door Parts (Hi Drum)

Air System

1.1 – #90796R

Description: DOOR – R.H. FRONT SUCTION DOOR (ILL.) (9900-9910)
OEM Part: AN190796
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

1.2 – #90797L

Description: DOOR – L.H. FRONT SUCTION DOOR (9900-9910)
OEM Part: AN190797
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

2.1 – #91116R

Description: DOOR – R.H. FRONT H-D SUCTION DOOR (ILL.) (9920-9930)
OEM Part: AN191116
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

2.2 – #91117L

Description: DOOR – L.H. FRONT H-D SUCTION DOOR (9920-9930)
OEM Part: AN191117
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

3 – #01893P

Description: BOLT – 1/4 X 1/2″ CARRIAGE BOLT
OEM Part: 03H1893
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

4 – #10217P

Description: NUT – 1/4 – SERR HEX FLANGE
OEM Part: N10217
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

5.1 – #91122R

Description: DOOR – R.H. CLEAN-OUT (ILL.) (9920-9930)
OEM Part: AN191122
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

5.2 – #91123L

Description: DOOR – L.H. CLEAN-OUT (9920-9930)
OEM Part: AN191123
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

6 – #92933

Description: LATCH – (9920-9930) . .
OEM Part: N192933
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

7.1 – #92718R

Description: TRANSITION – R.H. AIR DUCT TRANSITION (9900-9930)
OEM Part: AN192718
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

7.2 – #92719L

Description: TRANSITION – L.H. AIR DUCT TRANSITION (9900-9930)
OEM Part: AN192719
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

8 – #71292P

Description: BOLT – 5/16 X 1/2″ HEX HEAD FLANGE BOLT
OEM Part: N71292
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

9 – #10213P

Description: NUT – 5/16 – SERR HEX FLANGE
OEM Part: N10213
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

10.1 – #14216R

Description: NA – DOOR – R.H. REAR H-D SUCTION DOOR (ILL.) (9900-9930)
OEM Part: AN114216
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

10.2 – #14217L

Description: NA – DOOR – L.H. REAR H-D SUCTION DOOR (9900-9930)
OEM Part: AN114217
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

11 – #01774P

Description: BOLT – 5/16 X 5/8″ CARRIAGE
OEM Part: 03H1774
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

12 – #14820P

Description: BOLT – 1/4 X 1/2″ – SERR HEX FLANGE
OEM Part: N14820
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

13 – #10217P

Description: NUT – 1/4 – SERR HEX FLANGE
OEM Part: N10217
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

14 – #00206P

Description: PIN – 3/32 X 3/4 COTTER PIN
OEM Part: 11H206
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

15 – #34602

Description: PIN – CLEAN-OUT DOOR PIN
OEM Part: N34602
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

16 – #18875

Description: DOOR – CLEAN-OUT (9900-9930)
OEM Part: N118875
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

17.1 – #14826R

Description: DOOR – R.H. REAR H-D SUCTION DOOR (ILL.) (9940-9950)
OEM Part: AN114826
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

17.2 – #14827L

Description: DOOR – L.H. REAR H-D SUCTION DOOR (9940-9950)
OEM Part: AN114827
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)
Air System

18 – #90589

Description: DOOR – CLEAN-OUT, CONV. (9940-9950)
OEM Part: AN190589
Section: Air System
John Deere Front & Rear Suction Door Parts (Hi Drum)


John Deere 9935-65 In-Line Suction Door Parts

Air System

1 – #72383

Description: SUCTION DOOR – STRAIGHT (TALL) DOOR ASSEMBLY – 9960-9965 IN-LINE, (INCLUDES ITEMS #4 THRU #9)
OEM Part: AN272383
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

2.1 – #95147

Description: SUCTION DOOR – OFFSET RIGHT 5″ – DOOR ASSEMBLY – 9960-9965 IN-LINE – 38 & 40″ ROWS, (INCLUDES ITEMS #4 THRU #9)
OEM Part: AN195147
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

2.2 – #95147-X

Description: SUCTION DOOR – OFFSET LEFT 5″ – DOOR ASSEMBLY – 9960-9965 IN-LINE – USED ON ROW 1: CONVERTING TO 36″ ROWS FROM 38″ ( OPPOSITE OF PART #95147 ) (INCLUDES ITEMS #4 THRU #9)
OEM Part: 95147-X
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

3 – #93420

Description: SUCTION DOOR – STRAIGHT (SHORT) DOOR ASSEMBLY – 9960-9965 IN-LINE, (INCLUDES ITEMS #4 THRU #9)
OEM Part: AN193420
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

4 – #97195

Description: PIN – SUCTION DOOR ( 9935-CP690 IN-LINE & PRO )
OEM Part: N197195
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

5 – #00206P

Description: PIN – 3/32 X 3/4 COTTER PIN
OEM Part: 11H206
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

6 – #10217P

Description: NUT – 1/4 – SERR HEX FLANGE
OEM Part: N10217
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

7 – #94090

Description: LATCH – SUCTION DOOR (IN-LINE & PRO)
OEM Part: AN194090
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

8.1 – #99131

Description: SERVICE DOOR (9935-CP690) IN-LINE & PRO
OEM Part: N199131
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Ap99131

8.2 – #AP99131

Description: – ANTI PLUG – SERVICE DOOR (9935-CP690) IN-LINE & PRO – TAB TO PREVENT COTTON FROM GETTING CAUGHT IN HINGE
OEM Part: AP99131
Section:Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

9 – #01893P

Description: BOLT – 1/4 X 1/2″ CARRIAGE BOLT
OEM Part: 03H1893
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

10 – #14822P

Description: BOLT – 3/8 X 3/4″ – SERR HEX FLANGE
OEM Part: N14822
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts
Air System

11 – #10215P

Description: NUT – 3/8 – SERR HEX FLANGE
OEM Part: N10215
Section: Air System
John Deere 9935-65 In-Line Suction Door Parts


John Deere 9935-CP770 Pro Suction Door Parts

Air System

1.1 – #76846

Description: SUCTION DOOR – OFFSET RIGHT 11″ – INCLUDES ITEMS #13 THRU #18 (USE ON ROW: #2 ON 6 ROW, #1 ON 4 ROW: 30″ PRO-16 SKIP-ROW SETUP) (FITS: P-12 OR P-16)
OEM Part: AN276846
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

1.2 – #76846-SR

Description: SKIP ROW SUCTION DOOR – #76846 OFFSET TO THE LEFT 11″ – INCLUDES ITEMS #13 THRU #18
OEM Part: 76846-SR
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

2.1 – #76688

Description: SUCTION DOOR – OFFSET TO THE LEFT (9986-CP690) : REPLACES #AN273412 (9976) – INCLUDES ITEMS #13 THRU #18
OEM Part: AN276688
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

2.2 – #76688-SR

Description: SKIP ROW SUCTION DOOR – #76688 OFFSET TO THE RIGHT 5″ – INCLUDES ITEMS #13 THRU #18
OEM Part: AN275100
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

3 – #77607-B

Description: SHORT SUCTION DOOR (W/ BRACKET ON SIDES FOR 30-32″ ROWS) – (9986-CP690) : REPLACES #AN272788 (9935, 9970-9976) – INCLUDES ITEMS #13 THRU #18 (10.5″ VERTICAL OPENING)
OEM Part: AN277607
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

4 – #77607

Description: SHORT SUCTION DOOR – (9986-CP690) : REPLACES #AN272788 (9935, 9970-9976) – INCLUDES ITEMS #13 THRU #18 (10.5″ VERTICAL OPENING)
OEM Part: AN277607
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

5 – #76679

Description: STRAIGHT SUCTION DOOR – (9986-CP690) : REPLACES #AN272892 (9935, 9970-9976) – INCLUDES ITEMS #13 THRU #18
OEM Part: AN276679
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

6.1 – #77961

Description: SUCTION DOOR – BENT TO THE LEFT – PRO 16 – INCLUDES ITEMS #13 THRU #18 (9986-CP690)
OEM Part: AN277961
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

6.2 – #77961-SR

Description: SKIP ROW SUCTION DOOR – #77961 BENT TO THE RIGHT – INCLUDES ITEMS #13 THRU #18
OEM Part: 77961-SR
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

7 – #78691

Description: ANGLE – PRO SUCTION DOOR
OEM Part: N378691
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

8 – #63526P

Description: NUT – M10 – SERR HEX FLANGE
OEM Part: E63526
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

9 – #07190P

Description: BOLT – M10 X 20 ROUND HEAD – SQR NECK
OEM Part: 03M7190
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

10 – #72236

Description: AIR DUCT TRANSITION OUTER
OEM Part: AN272236
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

11.1 – #72239

Description: AIR DUCT TRANSITION – BENT TO THE LEFT
OEM Part: AN272239
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

11.2 – #72239-SR

Description: SKIP ROW AIR DUCT TRANSITION – #72239 BENT TO THE RIGHT
OEM Part: 72239-SR
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

12 – #07194P

Description: BOLT – M10 X 40 ROUND HEAD – SQR NECK
OEM Part: 03M7194
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
97195

13 – #97195

Description: PIN – SUCTION DOOR ( 9935-CP690 IN-LINE & PRO )
OEM Part: N197195
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

14 – #00206P

Description: PIN – 3/32 X 3/4 COTTER PIN
OEM Part: 11H206
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

15 – #10217P

Description: NUT – 1/4 – SERR HEX FLANGE
OEM Part: N10217
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

16 – #94090

Description: LATCH – SUCTION DOOR (IN-LINE & PRO)
OEM Part: AN194090
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

17.1 – #99131

Description: SERVICE DOOR (9935-CP690) IN-LINE & PRO
OEM Part: N199131
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Ap99131

17.2 – #AP99131

Description: – ANTI PLUG – SERVICE DOOR (9935-CP690) IN-LINE & PRO – TAB TO PREVENT COTTON FROM GETTING CAUGHT IN HINGE
OEM Part: AP99131
Section: Picking Unit Cabinet
John Deere 9900-9920, 9940 Picker Bar and Spindle Assembly
Air System

18 – #01893P

Description: BOLT – 1/4 X 1/2″ CARRIAGE BOLT
OEM Part: 03H1893
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

19 – #72893

Description: POST – INNER SHORT SUCTION DOOR SUPPORT
OEM Part: AN272893
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
76822

20 – #76822

Description: PIVOT ASSEMBLY – TELESCOPING DUCT (9970-CP690)
OEM Part: AN276822
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
71826

21 – #71826

Description: STRAP – DUCT REINFORCEMENT (9970-CP690)
OEM Part: N371826
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
73782

22 – #73782

Description: STRAP – PIVOT – TELESCOPING DUCT (9970-CP690)
OEM Part: N273782
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

23 – #07184P

Description: BOLT – M8 X 20 ROUND HEAD – SHORT SQR NECK
OEM Part: 03M7184
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
Air System

24 – #63525P

Description: NUT – M8 – SERR HEX FLANGE
OEM Part: E63525
Section: Air System
John Deere 9935-CP690 Pro Suction Door Parts
40466 Watermarked

25 – #40466

Description: BUSHING – SUCTION DOOR CONNECTION
OEM Part: H140466
Section: Air System
John Deere 9935-CP770 Pro Suction Door Parts
Air System

26 – #01730P

Description: WASHER – .410 X 1.5 X .120″
OEM Part: 24H1730
Section: Air System
John Deere 4 Row Fan Assembly
73439 Watermarked

27 – #73439

Description: PLATE – SIDE PIVOT PIN BRACKET- USED W/ SUCTION DOORS: 77607-B & KK24326
OEM Part: AN273439
Section: Air System
John Deere 9935-CP770 Pro Suction Door Parts
79440 Watermarked

28 – #79440

Description: CHANNEL – SIDE BRACKET – USED W/ SUCTION DOORS: 77607-B & KK24326
OEM Part: N279440
Section: Air System
John Deere 9935-CP770 Pro Suction Door Parts
98886 Watermarked

29 – #98886

Description: PLATE – SIDE OFFSET SUPPORT – USED W/ SUCTION DOORS: 77607-B & KK24326
OEM Part: N198886
Section: Air System
John Deere 9935-CP770 Pro Suction Door Parts
97264 Watermarked

30 – #97264

Description: PLATE – BACK BRACKET- USED W/ SUCTION DOORS: 77607-B & KK24326
OEM Part: N197264
Section: Air System
John Deere 9935-CP770 Pro Suction Door Parts
Picking Unit Cabinet

31 – #75620P

Description: BOLT – M10 X 20 – SERR HEX FLANGE – GD 8
OEM Part: N275620
Section: Picking Unit Cabinet
John Deere 9976-CP690 Lower Cabinet, Posts, and Doors
Picking Unit Cabinet

32 – #16931P

Description: PIN – SPRING LOCK PIN
OEM Part: J16931
Section: Picking Unit Cabinet
John Deere 9976-CP770 20S Pressure Plate Assembly


John Deere 2 Row Fan Assembly

Air System

1.1 – #92732F

Description: SIDE SUPPORT – BEARING (FRONT)
OEM Part: AN192732
Section: Air System
John Deere 2 Row Fan Assembly
Air System

1.2 – #92733R

Description: SIDE SUPPORT – BEARING (REAR)
OEM Part: AN192733
Section: Air System
John Deere 2 Row Fan Assembly
Air System

2 – #16690

Description: SIDE PANEL
OEM Part: N116690
Section: Air System
John Deere 2 Row Fan Assembly
Air System

3 – #16688

Description: BAFFLE – PLASTIC BAFFLE OR ORIFICE
OEM Part: N116688
Section: Air System
John Deere 2 Row Fan Assembly
Air System

4 – #20008

Description: WRAP AROUND COVER 2-ROW – WITH SERVICE HOLE
OEM Part: AN220008
Section: Air System
John Deere 2 Row Fan Assembly
Air System

5 – #14702

Description: ANGLE – USED FOR MOUNTING SHIM
OEM Part: N114702
Section: Air System
John Deere 2 Row Fan Assembly
Air System

6 – #14700

Description: CHANNEL – OUTLET SUPPORT CHANNEL
OEM Part: N114700
Section: Air System
John Deere 2 Row Fan Assembly
Air System

7 – #18257

Description: SHIM – SHIM USED ON FAN OUTLET
OEM Part: N118257
Section: Air System
John Deere 2 Row Fan Assembly
Air System

8 – #13793

Description: UNDER SHROUD – BOTTOM HOUSING CUTOFF, INCLUDES FOAM #AT35920
OEM Part: AN113793
Section: Air System
John Deere 2 Row Fan Assembly
Air System

9 – #14701

Description: TENSION BRKT
OEM Part: N114701
Section: Air System
John Deere 2 Row Fan Assembly
Air System

10 – #11234P

Description: NUT – 3/8 – NYLON LOCK
OEM Part: T11234
Section: Air System
John Deere 2 Row Fan Assembly
Air System

11 – #01305P

Description: WASHER – .406 X .810 X .060″
OEM Part: 24H1305
Section: Air System
John Deere 2 Row Fan Assembly
Air System

12 – #01304P

Description: WASHER – .406 X .718 X .120″
OEM Part: 24H1304
Section: Air System
John Deere 2 Row Fan Assembly
Air System

13 – #01726P

Description: BOLT – 3/8 X 2-1/4″ HEX HEAD
OEM Part: 19H1726
Section: Air System
John Deere 2 Row Fan Assembly
Air System

14 – #01540P

Description: BOLT – 5/16 X 3/4″ CARRIAGE
OEM Part: 03H1540
Section: Air System
John Deere 2 Row Fan Assembly
Air System

15 – #10213P

Description: NUT – 5/16 – SERR HEX FLANGE
OEM Part: N10213
Section: Air System
John Deere 2 Row Fan Assembly
Air System

16 – #01565P

Description: BOLT – 3/8 X 3″ CARRIAGE
OEM Part: 03H1565
Section: Air System
John Deere 2 Row Fan Assembly
Air System

17 – #01831P

Description: BOLT – 1/2 X 2″ HEX HEAD
OEM Part: 19H1831
Section: Air System
John Deere 2 Row Fan Assembly
Air System

18 – #00301P

Description: WASHER – 1/2″ LOCK
OEM Part: 12H301
Section: Air System
John Deere 2 Row Fan Assembly
Air System

19 – #01254P

Description: WASHER – 17/32 X 1-1/8 X .105″
OEM Part: 24H1254
Section: Air System
John Deere 2 Row Fan Assembly
Air System

20 – #90049P

Description: SHEAVE – WATER PULLEY (9900-9996)
OEM Part: N190049
Section: Air System
John Deere 2 Row Fan Assembly
Air System

21 – #96112

Description: BUSHING – WATER PULLEY
OEM Part: N196112
Section: Air System
John Deere 2 Row Fan Assembly
Air System

22.1 – #14202P

Description: 1-3/8 BRG ASSY, INCLUDES HOUSING AND LOCKING COLLAR
OEM Part: AN114202
Section: Air System
John Deere 2 Row Fan Assembly
Air System

22.2 – #12851P

Description: 1-1/8 BRG ASSY – INCLUDES HOUSING AND LOCKING COLLAR
OEM Part: AN112851
Section: Air System
John Deere 2 Row Fan Assembly
Air System

23 – #96398

Description: SHAFT – 1-3/8 X 17.875 BLOWER SHAFT
OEM Part: N196398
Section: Air System
John Deere 2 Row Fan Assembly
Air System

24 – #96396P

Description: SNAP RING
OEM Part: N196396
Section: Air System
John Deere 2 Row Fan Assembly
Air System

25 – #96397

Description: STOP COLLAR
OEM Part: N196397
Section: Air System
John Deere 2 Row Fan Assembly
Air System

26 – #19769

Description: FAN BLADE 2 ROW
OEM Part: N119769
Section: Air System
John Deere 2 Row Fan Assembly
Air System

27 – #19580

Description: SHAFT SPACER – 1.4 X 1.875 X 4.575
OEM Part: N119580
Section: Air System
John Deere 2 Row Fan Assembly
Air System

28 – #01480P

Description: BOLT – 3/8 X 1-1/2″ CARRIAGE
OEM Part: 03H1480
Section: Air System
John Deere 2 Row Fan Assembly
Air System

29 – #11234P

Description: NUT – 3/8 – NYLON LOCK
OEM Part: T11234
Section: Air System
John Deere 2 Row Fan Assembly
Air System

30 – #00040P

Description: KEY – 1/4 X 2-1/8 WOODRUFF
OEM Part: 26H40
Section: Air System
John Deere 2 Row Fan Assembly
Air System

31 – #00222P

Description: COTTER PIN – 3/16 X 2
OEM Part: 11H222
Section: Air System
John Deere 2 Row Fan Assembly
Air System

32 – #00530P

Description: WASHER – 1.390 X 2.125 X .135″
OEM Part: 24H530
Section: Air System
John Deere 2 Row Fan Assembly
Air System

33 – #01511P

Description: WASHER – 1-13/32 X 1-3/4 X .060″
OEM Part: 24H1511
Section: Air System
John Deere 2 Row Fan Assembly
Air System

34 – #01558P

Description: BOLT – 3/8 X 1-3/4″ CARRIAGE
OEM Part: 03H1558
Section: Air System
John Deere 2 Row Fan Assembly
Air System

35 – #00641P

Description: WASHER – 1-1/16 X 2 X .134″
OEM Part: 24H641
Section: Air System
John Deere 2 Row Fan Assembly
Air System

36 – #00535P

Description: NUT – 1-14 CASTLE
OEM Part: C535R
Section: Air System
John Deere 2 Row Fan Assembly
Air System

37 – #07185P

Description: BOLT – M8 X 25 ROUND HEAD – SHORT SQR NECK
OEM Part: 03M7185
Section: Air System
John Deere 2 Row Fan Assembly
Air System

38 – #20401

Description: COVER – 2R FAN WRAP INSPECTION
OEM Part: N220401
Section: Air System
John Deere 2 Row Fan Assembly
Air System

39 – #47159

Description: CLIP – 2R FAN WRAP INSPECTION
OEM Part: P47159
Section: Air System
John Deere 2 Row Fan Assembly
Air System

40 – #07020P

Description: M8 WING NUT- 2R FAN WRAP INSPECTION
OEM Part: 14M7020
Section: Air System
John Deere 2 Row Fan Assembly
Air System

41 – #29368P

Description: BELT – 2 ROW FAN DRIVE – JD (FAN ASSY #15233) . .
OEM Part: N129368
Section: Air System
John Deere 2 Row Fan Assembly
74103f

42 – #74103F

Description: FRAME SUPPORT – FRONT 2ROW – 1.5″ SHAFT
OEM Part: AN274103
Section: Air System
John Deere 2 Row Fan Assembly
Air System

43 – #74104R

Description: FRAME SUPPORT – REAR 2ROW – 1.5″ SHAFT
OEM Part: AN274104
Section: Air System
John Deere 2 Row Fan Assembly
Air System

44 – #76865

Description: BAFFLE 2-ROW – METRIC HOLES
OEM Part: N276865
Section: Air System
John Deere 2 Row Fan Assembly
Air System

45 – #63526P

Description: NUT – M10 – SERR HEX FLANGE
OEM Part: E63526
Section: Air System
John Deere 2 Row Fan Assembly
Air System

46 – #07400P

Description: NUT – M10-1.5 – NYLON LOCK
OEM Part: 14M7400
Section: Air System
John Deere 2 Row Fan Assembly
Air System

47 – #07156P

Description: BOLT – M10 X 60 HEX HEAD
OEM Part: 19M7156
Section: Air System
John Deere 2 Row Fan Assembly
Air System

48 – #63525P

Description: NUT – M8 – SERR HEX FLANGE
OEM Part: E63525
Section: Air System
John Deere 2 Row Fan Assembly
Air System

49 – #63115P

Description: .406 X 1.25 X .104 WASHER – REINFORCEMENT
OEM Part: M63115
Section: Air System
John Deere 2 Row Fan Assembly
Air System

50 – #07054P

Description: BOLT – M8 X 20 ROUND HEAD – SQR NECK
OEM Part: 03M7054
Section: Air System
John Deere 2 Row Fan Assembly
Air System

51 – #07184P

Description: BOLT – M8 X 20 ROUND HEAD – SHORT SQR NECK
OEM Part: 03M7184
Section: Air System
John Deere 2 Row Fan Assembly
Air System

52 – #07218P

Description: BOLT – M10 X 80 ROUND HEAD – SHORT SQR NECK
OEM Part: 03M7218
Section: Air System
John Deere 2 Row Fan Assembly
Air System

53 – #75038P

Description: PRO DOFFER NUT, M30 NYLON LOCK NUT (9935-CP690 P12)
OEM Part: N275038
Section: Air System
John Deere 2 Row Fan Assembly
Air System

54 – #63527P

Description: NUT – M12 – SERR HEX FLANGE
OEM Part: E63527
Section: Air System
John Deere 2 Row Fan Assembly
Air System

55 – #74105P

Description: PILLOW BLOCK BEARING ASSY 2-ROW – 1.5″ SHAFT
OEM Part: AN274105
Section: Air System
John Deere 2 Row Fan Assembly
Air System

56 – #07813P

Description: BOLT – M12 X 45 – SMOOTH HEX FLANGE
OEM Part: 19M7813
Section: Air System
John Deere 2 Row Fan Assembly
Air System

57 – #18111

Description: SHORT SLEEVE – 2-ROW FAN – 1.5″ SHAFT
OEM Part: M18111
Section: Air System
John Deere 2 Row Fan Assembly
Air System

58 – #97459

Description: TONEWHEEL
OEM Part: N197459
Section: Air System
John Deere 2 Row Fan Assembly
Air System

59 – #76868

Description: 2 ROW FAN SHAFT – 1.5″ DIA
OEM Part: N276868
Section: Air System
John Deere 2 Row Fan Assembly
Air System

60 – #76866

Description: FAN BLADE 2 ROW – 1.50″ BORE
OEM Part: N276866
Section: Air System
John Deere 2 Row Fan Assembly
Air System

61 – #76867

Description: LONG SPACER – 2 ROW FAN SHAFT- 1.5″ SHAFT
OEM Part: N276867
Section: Air System
John Deere 2 Row Fan Assembly
Air System

62 – #01535P

Description: WASHER – 1-17/32 X 1-31/32 X .035″
OEM Part: 24H1535
Section: Air System
John Deere 2 Row Fan Assembly
Air System

63 – #21237

Description: ANGLE – BELT GUARD – 2 ROW FAN
OEM Part: N221237
Section: Air System
John Deere 2 Row Fan Assembly
Air System

64 – #08306P

Description: BOLT – M12 X 50 – SMOOTH HEX FLANGE
OEM Part: 19M8306
Section: Air System
John Deere 2 Row Fan Assembly
Air System

65 – #90738P

Description: 1-1/2 BRG ASSY – INCLUDES HOUSING AND LOCKING COLLAR
OEM Part: AN190738
Section: Air System
John Deere 2 Row Fan Assembly
Air System

66 – #9611094P

Description: WASHER – 1.75 X .937 X .13 HDN
OEM Part: 24M7091
Section: Air System
John Deere 2 Row Fan Assembly
Air System

67 – #31871P

Description: NUT – M24 – HEX STOVER LOCK
OEM Part: A31871
Section: Air System
John Deere 2 Row Fan Assembly
Air System

68 – #B20907

Description: FAN ROTOR – 9935 – Belt-Fan Drive (2 Band) – Eff.L78.750 IN – W.66 IN – T.41 IN (FAN ASSY #74106)
OEM Part: N220907
Section: Air System
John Deere 2 Row Fan Assembly
15233

KIT.1 – #15233

Description: 2 ROW FAN KIT – 1-3/8″ SHAFT, ALL PARTS UNASSEMBLED INCLUDES #07200 BOLT KIT – (W/O #90049P SHEAVE) (9930CP, 7440CS)
OEM Part: AN115233
Section: Air System
John Deere 2 Row Fan Assembly
74106

KIT.4 – #74106

Description: 2 ROW FAN KIT – ALL PARTS UNASSEMBLED INCLUDES #74106BK BOLT KIT (9935CP, 7455CS) (MAY USE WATER PULLEY AND BUSHING ON MODELS 9900-30CP &7440CS) DOES NOT INCLUDE BELT GUARD # 21237
OEM Part: AN274106
Section: Air System
John Deere 2 Row Fan Assembly
Air System

KIT.2 – #15233A

Description: 2 ROW FAN KIT – 1-3/8″ SHAFT, ALL PARTS ASSEMBLED – (W/O #90049P SHEAVE) (9930CP, 7440CS)
OEM Part: 15233A
Section: Air System
John Deere 2 Row Fan Assembly
Air System

KIT.3 – #07200

Description: BOLT KIT – COMPLETE FOR 2 ROW FAN ASSEMBLY #15233 (DOES NOT INCLUDE ITEMS 37-40)
OEM Part: 7200
Section: Air System
John Deere 2 Row Fan Assembly
74106a

KIT.5 – #74106A

Description: 2 ROW FAN KIT – ALL PARTS ASSEMBLED (9935CP, 7455CS) (MAY USE WATER PULLEY AND BUSHING ON MODELS 9900-30CP & 7440CS) DOES NOT INCLUDE BELT GUARD # 21237
OEM Part: 74106A
Section: Air System
John Deere 2 Row Fan Assembly
Air System

KIT.6 – #74106BK

Description: BOLT KIT – COMPLETE FOR 2 ROW FAN ASSEMBLY #74106 (9935CP, 7455CS) (DOES NOT INCLUDE ITEMS 37-40)
OEM Part: 74106BK
Section: Air System
John Deere 2 Row Fan Assembly


John Deere 4 Row Fan Assembly

Air System

1.1 – #93514F

Description: SIDE SUPPORT – BEARING (FRONT)
OEM Part: AN193514
Section: Air System
John Deere 4 Row Fan Assembly
Air System

1.2 – #93515R

Description: SIDE SUPPORT – BEARING (REAR)
OEM Part: AN193515
Section: Air System
John Deere 4 Row Fan Assembly
Air System

2 – #18515

Description: SIDE PANEL
OEM Part: N118515
Section: Air System
John Deere 4 Row Fan Assembly
Air System

3 – #92872P

Description: ISOLATOR – 1/2 X 3/4 X 48″-52″ FOAM PAD
OEM Part: N192872
Section: Air System
John Deere 4 Row Fan Assembly
Air System

4 – #96088

Description: BAFFLE – PLASTIC BAFFLE OR ORIFICE
OEM Part: N196088
Section: Air System
John Deere 4 Row Fan Assembly
Air System

5 – #14674

Description: WRAP AROUND – HOUSING
OEM Part: AN114674
Section: Air System
John Deere 4 Row Fan Assembly
Air System

6 – #14675

Description: UNDER SHROUD – BOTTOM HOUSING CUTOFF, INCLUDES FOAM #AT35920
OEM Part: AN114675
Section: Air System
John Deere 4 Row Fan Assembly
Air System

7 – #18518

Description: TENSION BRKT
OEM Part: N118518
Section: Air System
John Deere 4 Row Fan Assembly
Air System

8 – #19024

Description: SHIM – FOR FAN OUTLET
OEM Part: N119024
Section: Air System
John Deere 4 Row Fan Assembly
Air System

9 – #18516

Description: ANGLE – USED FOR MOUNTING SHIM
OEM Part: N118516
Section: Air System
John Deere 4 Row Fan Assembly
Air System

10 – #18517

Description: CHANNEL – OUTLET SUPPORT
OEM Part: N118517
Section: Air System
John Deere 4 Row Fan Assembly
Air System

11 – #11234P

Description: NUT – 3/8 – NYLON LOCK
OEM Part: T11234
Section: Air System
John Deere 4 Row Fan Assembly
Air System

12 – #01302P

Description: WASHER – .406 X .6875 X .035″
OEM Part: 24H1302
Section: Air System
John Deere 4 Row Fan Assembly
Air System

13 – #01304P

Description: WASHER – .406 X .718 X .120″
OEM Part: 24H1304
Section: Air System
John Deere 4 Row Fan Assembly
Air System

14 – #01305P

Description: WASHER – .406 X .810 X .060″
OEM Part: 24H1305
Section: Air System
John Deere 4 Row Fan Assembly
Air System

15 – #40003P

Description: NUT – 3/8 – JAM STYLE LOCK
OEM Part: K40003-F
Section: Air System
John Deere 4 Row Fan Assembly
Air System

16 – #01305P

Description: WASHER – .406 X .810 X .060″
OEM Part: 24H1305
Section: Air System
John Deere 4 Row Fan Assembly
Air System

17 – #02069

Description: SPACER – SPACER INSIDE OF BAFFLE
OEM Part: 28H2069
Section: Air System
John Deere 4 Row Fan Assembly
Air System

18 – #01730P

Description: WASHER – .410 X 1.5 X .120″
OEM Part: 24H1730
Section: Air System
John Deere 4 Row Fan Assembly
Air System

19 – #91671

Description: WASHER – CUPPED WASHER FROM .380 X 2.5 X .120
OEM Part: N191671
Section: Air System
John Deere 4 Row Fan Assembly
Air System

20 – #02978P

Description: BOLT – 3/8 X 5″ HEX HEAD BOLT WITH FULL THREADS
OEM Part: 19H2978
Section: Air System
John Deere 4 Row Fan Assembly
Air System

21 – #01540P

Description: BOLT – 5/16 X 3/4″ CARRIAGE
OEM Part: 03H1540
Section: Air System
John Deere 4 Row Fan Assembly
Air System

22 – #10213P

Description: NUT – 5/16 – SERR HEX FLANGE
OEM Part: N10213
Section: Air System
John Deere 4 Row Fan Assembly
Air System

23 – #01565P

Description: BOLT – 3/8 X 3″ CARRIAGE
OEM Part: 03H1565
Section: Air System
John Deere 4 Row Fan Assembly
Air System

24 – #01709P

Description: BOLT – 5/16 X 1″ CARRIAGE
OEM Part: 03H1709
Section: Air System
John Deere 4 Row Fan Assembly
Air System

25 – #01831P

Description: BOLT – 1/2 X 2″ HEX HEAD
OEM Part: 19H1831
Section: Air System
John Deere 4 Row Fan Assembly
Air System

26 – #00301P

Description: WASHER – 1/2″ LOCK
OEM Part: 12H301
Section: Air System
John Deere 4 Row Fan Assembly
Air System

27 – #01254P

Description: WASHER – 17/32 X 1-1/8 X .105″
OEM Part: 24H1254
Section: Air System
John Deere 4 Row Fan Assembly
Air System

28 – #90049P

Description: SHEAVE – WATER PULLEY (9900-9996)
OEM Part: N190049
Section: Air System
John Deere 4 Row Fan Assembly
Air System

29 – #96112

Description: BUSHING – WATER PULLEY
OEM Part: N196112
Section: Air System
John Deere 4 Row Fan Assembly
Air System

30 – #90738P

Description: 1-1/2 BRG ASSY – INCLUDES HOUSING AND LOCKING COLLAR
OEM Part: AN190738
Section: Air System
John Deere 4 Row Fan Assembly
Air System

31 – #93687

Description: BRACKET, 4 ROW FAN, TACK ANGLE BRACKET
OEM Part: N193687
Section: Air System
John Deere 4 Row Fan Assembly
Air System

32 – #97459

Description: TONEWHEEL
OEM Part: N197459
Section: Air System
John Deere 4 Row Fan Assembly
96111

33 – #96111

Description: SHAFT – 1-1/2 X 24.469 BLOWER SHAFT
OEM Part: N196111
Section: Air System
John Deere 4 Row Fan Assembly
Air System

34 – #96350P

Description: SNAP RING
OEM Part: N196350
Section: Air System
John Deere 4 Row Fan Assembly
Air System

35 – #96110

Description: STOP COLLAR
OEM Part: N196110
Section: Air System
John Deere 4 Row Fan Assembly
Air System

36 – #96676

Description: FAN BLADE – FAN BLADE 4 ROW
OEM Part: N196676
Section: Air System
John Deere 4 Row Fan Assembly
Air System

37 – #95331

Description: SPACER – 1.525 X 2.0 X 6.341
OEM Part: N195331
Section: Air System
John Deere 4 Row Fan Assembly
Air System

38 – #62934P

Description: NUT – 1/2 – SERR HEX FLANGE
OEM Part: E62934
Section: Air System
John Deere 4 Row Fan Assembly
Air System

39 – #01492P

Description: BOLT – 1/2 X 2″ CARRIAGE
OEM Part: D3H1492
Section: Air System
John Deere 4 Row Fan Assembly
Air System

40 – #00040P

Description: KEY – 1/4 X 2-1/8 WOODRUFF
OEM Part: 26H40
Section: Air System
John Deere 4 Row Fan Assembly
Air System

41 – #00250P

Description: COTTER PIN – 1/4 X 2-1/2″
OEM Part: 11H250
Section: Air System
John Deere 4 Row Fan Assembly
11540

42 – #11540

Description: WASHER – 1-17/32 X 2-1/2 X 1/4
OEM Part: 24H1540
Section: Air System
John Deere 4 Row Fan Assembly
Air System

43 – #01535P

Description: WASHER – 1-17/32 X 1-31/32 X .035″
OEM Part: 24H1535
Section: Air System
John Deere 4 Row Fan Assembly
Air System

44 – #01777P

Description: BOLT – 1/2 X 1-3/4″ – SERR HEX FLANGE
OEM Part: 19H1777
Section: Air System
John Deere 4 Row Fan Assembly
Air System

45 – #01499P

Description: WASHER – 1-9/32 X 2-1/4 X .134″
OEM Part: 24H1499
Section: Air System
John Deere 4 Row Fan Assembly
Air System

46 – #00927P

Description: NUT – 1-1/4-12 CASTLE
OEM Part: 14H927
Section: Air System
John Deere 4 Row Fan Assembly
Air System

47 – #93822P

Description: BELT – 4 ROW FAN DRIVE – JD
OEM Part: N193822
Section: Air System
John Deere 4 Row Fan Assembly
07440

KIT.1 – #07440

Description: 4 ROW FAN KIT – ALL PARTS UNASSEMBLED INCLUDES #07400 BOLT KIT ( NO PULLEY )
OEM Part: AN193785
Section: Air System
John Deere 4 Row Fan Assembly
Air System

KIT.2 – #07440A

Description: 4 ROW FAN KIT – ALL PARTS ASSEMBLED ( NO PULLEY )
OEM Part: AN193785
Section: Air System
John Deere 4 Row Fan Assembly
Air System

KIT.3 – #07400

Description: BOLT KIT – COMPLETE FOR 4 ROW FAN ASSEMBLY
OEM Part: 7400
Section: Air System
John Deere 4 Row Fan Assembly
Air System

26 – #01730P

Description: WASHER – .410 X 1.5 X .120″
OEM Part: 24H1730
Section: Air System
John Deere 4 Row Fan Assembly
